gvi70000
Membru Puf
Inregistrat: acum 13 ani
|
|
Salut, Am un NaviMate 35S care s-a blocat la logo. Am incercat sa-i fac: 1. Update de firmware cu cel de pe site dar nu se intampla nimic; 2. Update de firmware cu cel de la 43S se face dar nu se intelege nimic din cauza diferentei de marime a ecranului; 3. Update de firmware cu Atlas_Manager_6.1.4 folosind 1 si cardul cu firmware-ul original in dispozitiv - merge dar ecranul este offset-at cu 1cm atat pe orizontala cat si pe verticala 4. Update de firmware cu cel postat de ablbd de pe card dar iar nu se intampla nimic 5. Update de firmware cu Atlas_Manager_6.1.4 cu cel postat de ablbd cu cardul in dispozitiv dar este la fel ca la punctul 3
La System information imi spune: Model: FPN1043BT Version: HC-A3-35-01-1809090428 UUID: FFFFFFFFFFFFFFFF
SN: 200904067
CPU SIRF Atlas iii N0K213 00S-1LF Nand: Hynix HY27US08121A
AtlasMgr zice i stanga jos
Version: 4.00 CPU Type: 0x00010000 Hardware name: ACE Software name: AT4X0BD Image type: NBoot
Iar dupa ce fac update-ul obtin
Centrality NBOOT v5.0 May 07 2008 15:19:07
1): Launch EBOOT 2): Erase and Reset TOC Input:------ 0x0000001D0x0114C632 Microsoft Windows CE Ethernet Bootloader Common Library Version 1.1 Built May 6 2008 10:03:00 Centrality Windows CE Atlas Bootloader Version 3.2 Built May 6 2008 10:02:50 dwCacheInfo = 0x1D152152 EBOOT Version = 0x300B BspNandGetTiming: dwManuID = 0x0, dwDevID = 0x0
BspNandGetTiming: dwManuID = 0xAD, dwDevID = 0x76
BspNandGetExtInfo: dwManuID = 0xAD, dwDevID = 0x76
BspNandGetTiming: dwManuID = 0xFE, dwDevID = 0xFF
BspNandGetExtInfo: dwManuID = 0xFE, dwDevID = 0xFF
BspNandGetTiming: dwManuID = 0xFE, dwDevID = 0xFF
BspNandGetExtInfo: dwManuID = 0xFE, dwDevID = 0xFF
FMD: (ReadUUID from the first sector in block: 12)
TOC { dwSignature: 0x434F544E BootCfg { ConfigFlags: 0x3860 BootDelay: 0xF ImageIndex: 1 IP: 0.0.0.0 MAC Address: 00:00:00:00:00:00 Port: 0.0.0.0 SubnetMask: 0.0.0.0 } ID[0] { dwVersion: 0x300B dwSignature: 0x45424F54 String: 'eboot.nb0' dwImageType: 0x2 dwTtlSectors: 0x140 dwLoadAddress: 0x8C04C000 dwJumpAddress: 0x8C04C000 dwStartBlock: 0x2 dwStoreOffset: 0x0 sgList[0].dwSector: 0x40 sgList[0].dwLength: 0x140 } ID[1] { dwVersion: 0x1 dwSignature: 0x43465348 String: 'PPC2K3.NB0' dwImageType: 0xE dwTtlSectors: 0x1B39 dwLoadAddress: 0x8C4AA000 dwJumpAddress: 0x8C4AB000 dwStartBlock: 0x1E dwStoreOffset: 0x0 sgList[0].dwSector: 0x3C1 sgList[0].dwLength: 0x1B39 } ID[2] { dwVersion: 0x1 dwSignature: 0x45424F54 String: 'DM' dwImageType: 0x2 dwTtlSectors: 0x20 dwLoadAddress: 0x8C04C000 dwJumpAddress: 0x8C04C000 dwStartBlock: 0xC dwStoreOffset: 0x0 sgList[0].dwSector: 0x180 sgList[0].dwLength: 0x20 } chainInfo.dwLoadAddress: 0x8C2A0000 chainInfo.dwFlashAddress: 0x00012BC1 chainInfo.dwLength: 0x00000020 nandxipInfo.dwCodePages: 0 nandxipInfo.dwCopies: 0 nandxipInfo.dwBlockNo: 0x00000000 nandxipInfo.dwCodePages: 0 nandxipInfo.dwCopies: 0 } Image block starts at physical block 30 virtual block 30 WARNING: OEMPlatformInit failed to initialize Ethernet controller.
@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@ SDMMC card is detected! SDMMC_Init successfully!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! ! Now we try to update logo from SD card. Please ensure ! your raw data image in SD card root directory. ! Note here you must place only startup.raw file ! in SD card. Here you have three choice: ! 1 ----- Download now ! 2 ----- Erase Updated logo ! 4 ----- Change Logo Display Size ! 9 ----- Give up to download image !Now only disport 4.3 inch and 3.5 inch: !If you choose 4 ,The size will auto changed: !Now Logo DisPlay Size is: Width: 480, Heigh: 272
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
Do what you want to download: input 1 Try to download raw data image. open logo!g_pTOC->logo.dwValid=0 Can't open startup.raw file! Download raw data image failed!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! ! Now we try to update image from SD card. Please ensure ! your Monolithic or MultiXIP image in SD card root dire- ! ctory. Note here you must place only Monolithic or Mul- ! tiXIP image in SD card. If you select to doenload Mono- ! lithic image and put MultiXIP image in SD card, there ! will be errors! Vice versa. Here you have three choice: ! 1 ----- MultiXIP ! 2 ----- Monolithic ! 9 ----- Give up to download image !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
Do what you want to download: input 1 Try to download MultiXIP image. Atlas_LCDX: poweron lcd!
ROMHDR at Address 8C4AA044h ::OEMLaunch, ImageStart:0x8C4AA000, ImageLength:0x367034, LaunchAddr:0x8C4AB000 OEMLaunch: Write image to nandflash OEMLaunch: (IMAGE_TYPE_MXIP|IMAGE_TYPE_BINFS) +WriteRegionsToBootMedia: ImageStart: 0x8C4AA000, ImageLength: 0x367034, LaunchAddr:0x8C4AB000 INFO: OEMLaunch: Found chain extenstion: '' @ 0x8C4AA000 INFO: OEMLaunch: Found chain extenstion: 'chain information' @ 0x8C4AA000 INFO: OEMLaunch: Found 'chain information' (pChainInfo=0x8E19D7F0 Extensions=0x4). Found the Chain region: StartAddress: 0x8C2A0000; Length: 0x000007B8 Writing multi-regions BINFSPartMaxLength[0]: 0x4000, TtlBINFSPartLength: 0x4000 dwMaxRegionLength[3]: 0x4000 BINFSPartMaxLength[1]: 0x400000, TtlBINFSPartLength: 0x404000 dwMaxRegionLength[0]: 0x400000 BINFSPartMaxLength[2]: 0x600000, TtlBINFSPartLength: 0xA04000 dwMaxRegionLength[1]: 0x600000 BINFSPartMaxLength[3]: 0x1B00000, TtlBINFSPartLength: 0x2504000 dwMaxRegionLength[2]: 0x1B00000 Open/create BINFS partition 75840 sectors... IsValidMBR: MBR sector = 0x3C0
OpenPartition: Partition Exists=0x1 for part 0x21.
*************WriteRegionsToBootMedia 1 Sectors:75839*************
dwRegionStart: 0x8E000000, dwRegionLength: 0x367034, dwStoreOffset: 0x0 BP_SetDataPointer at 0x0
WriteData: Start = 0x0, Length = 0x367034.
Log2Phys: Logical 0x1 -> Physical 0x3C1
Updateded TOC! dwRegionStart: 0x8E367034, dwRegionLength: 0x1F7B00, dwStoreOffset: 0x400000 BP_SetDataPointer at 0x400000
WriteData: Start = 0x400000, Length = 0x1F7B00.
Log2Phys: Logical 0x2001 -> Physical 0x23C1
dwRegionStart: 0x8E55EB34, dwRegionLength: 0x16C10EC, dwStoreOffset: 0xA00000 BP_SetDataPointer at 0xA00000
WriteData: Start = 0xA00000, Length = 0x16C10EC.
Log2Phys: Logical 0x5001 -> Physical 0x53C1
dwRegionStart: 0x8FC1FC20, dwRegionLength: 0x7B8, dwStoreOffset: 0x2500000 BP_SetDataPointer at 0x2500000
WriteData: Start = 0x2500000, Length = 0x7B8.
Log2Phys: Logical 0x12801 -> Physical 0x12BC1
Written Chain Region to the Flash LoadAddress = 0x8C2A0000; FlashAddress = 0x00012BC1; Length = 0X00000020
IsValidMBR: MBR sector = 0x3C0
OpenPartition: Partition Exists=0x1 for part 0x21.
Image start sector: 961, total sectors: 75839
Please wait for calculating checksum...
CUR: ImageDataCheckSum: 0x2D2702DA, ImageInfoCheckSum: 0x5AB9BAA
TOC: ImageDataCheckSum: 0x2CCB2D8A, ImageInfoCheckSum: 0x5AB9BAA
FindFreeSector: FreeSector is: 0x12840 after processing part 0x21.
FindFreeSector: FreeSector is: 0x1DF20 after processing part 0x12.
FindFreeSector: FreeSector is: 0x1E1A0 after processing part 0x4.
FindFreeSector: FreeSector is: 0x1F9C0 after processing part 0x11.
LastLogSector: Last log sector is: 0x1FAFF.
Datastorge Size: -6816 FindFreeSector: FreeSector is: 0x12840 after processing part 0x21.
FindFreeSector: FreeSector is: 0x1DF20 after processing part 0x12.
FindFreeSector: FreeSector is: 0x1E1A0 after processing part 0x4.
FindFreeSector: FreeSector is: 0x1F9C0 after processing part 0x11.
GetRemainingSpace: -32 FindFreeSector: FreeSector is: 0x12840 after processing part 0x21.
FindFreeSector: FreeSector is: 0x1DF20 after processing part 0x12.
FindFreeSector: FreeSector is: 0x1E1A0 after processing part 0x4.
FindFreeSector: FreeSector is: 0x1F9C0 after processing part 0x11.
IsValidMBR: MBR sector = 0x3C0
OpenPartition: Partition Exists=0x1 for part 0x12.
FindFreeSector: FreeSector is: 0x12840 after processing part 0x21.
FindFreeSector: FreeSector is: 0x1DF20 after processing part 0x12.
FindFreeSector: FreeSector is: 0x1E1A0 after processing part 0x4.
FindFreeSector: FreeSector is: 0x1F9C0 after processing part 0x11.
*************WriteRegionsToBootMedia 1 Sectors:4294960480*************
FindFreeSector: FreeSector is: 0x12840 after processing part 0x21.
FindFreeSector: FreeSector is: 0x1DF20 after processing part 0x12.
FindFreeSector: FreeSector is: 0x1E1A0 after processing part 0x4.
FindFreeSector: FreeSector is: 0x1F9C0 after processing part 0x11.
IsValidMBR: MBR sector = 0x3C0
OpenPartition: Partition Exists=0x1 for part 0x4.
FindFreeSector: FreeSector is: 0x12840 after processing part 0x21.
FindFreeSector: FreeSector is: 0x1DF20 after processing part 0x12.
FindFreeSector: FreeSector is: 0x1E1A0 after processing part 0x4.
FindFreeSector: FreeSector is: 0x1F9C0 after processing part 0x11.
*************WriteRegionsToBootMedia 1 Sectors:4294961120*************
Creating a additional hide FAT partition to store hive-based registry IsValidMBR: MBR sector = 0x3C0
OpenPartition: Partition Exists=0x1 for part 0x11.
*************WriteRegionsToBootMedia 1 Sectors:4294967295*************
-WriteRegionsToBootMedia FindFreeSector: FreeSector is: 0x12840 after processing part 0x21.
FindFreeSector: FreeSector is: 0x1DF20 after processing part 0x12.
FindFreeSector: FreeSector is: 0x1E1A0 after processing part 0x4.
FindFreeSector: FreeSector is: 0x1F9C0 after processing part 0x11.
GetBaseFMDBlock: MBR block 30, Total Unusable Blk 30, start logic sector 0x1F9C0 Start block NO. for new FMD driver should be 0xFF0 +TOC_Write Erasing Block: 1
-TOC_Write TOC { dwSignature: 0x434F544E BootCfg { ConfigFlags: 0x3860 BootDelay: 0xF ImageIndex: 1 IP: 0.0.0.0 MAC Address: 00:00:00:00:00:00 Port: 0.0.0.0 SubnetMask: 0.0.0.0 } ID[0] { dwVersion: 0x300B dwSignature: 0x45424F54 String: 'eboot.nb0' dwImageType: 0x2 dwTtlSectors: 0x140 dwLoadAddress: 0x8C04C000 dwJumpAddress: 0x8C04C000 dwStartBlock: 0x2 dwStoreOffset: 0x0 sgList[0].dwSector: 0x40 sgList[0].dwLength: 0x140 } ID[1] { dwVersion: 0x1 dwSignature: 0x43465348 String: 'PPC2K3.NB0' dwImageType: 0xE dwTtlSectors: 0x1B39 dwLoadAddress: 0x8C4AA000 dwJumpAddress: 0x8C4AB000 dwStartBlock: 0x1E dwStoreOffset: 0x0 sgList[0].dwSector: 0x3C1 sgList[0].dwLength: 0x1B39 } ID[2] { dwVersion: 0x1 dwSignature: 0x45424F54 String: 'DM' dwImageType: 0x2 dwTtlSectors: 0x20 dwLoadAddress: 0x8C04C000 dwJumpAddress: 0x8C04C000 dwStartBlock: 0xC dwStoreOffset: 0x0 sgList[0].dwSector: 0x180 sgList[0].dwLength: 0x20 } chainInfo.dwLoadAddress: 0x8C2A0000 chainInfo.dwFlashAddress: 0x00012BC1 chainInfo.dwLength: 0x00000020 nandxipInfo.dwCodePages: 0 nandxipInfo.dwCopies: 0 nandxipInfo.dwBlockNo: 0x00000000 nandxipInfo.dwCodePages: 0 nandxipInfo.dwCopies: 0 }
Jumping to image at virtual address 0x8C4AB000h +ToPhysicalAddr:0x8C4AB000 -ToPhysicalAddr:0xC04AB000
::: Physical Launch Address: 0xC04AB000h
